As we all know, [Hexagons are the Bestagons](https://www.youtube.com/watch?v=thOifuHs6eY) - we see them in honeycombs, they are in snowflakes and pencils, there’s one [on Saturn](https://en.wikipedia.org/wiki/Saturn%27s_hexagon), and they are... *(math incoming)* the only regular polygon to tile a plane without resorting to debasing self-divison 😅.

When I started rebuilding my website, I knew I wanted a live, configurable background and it quickly became clear it’ll be rendered on a **canvas**. I was playing around, drawing various 2D shapes, when I remembered the [CGP Grey](https://www.youtube.com/greymatter) video - hexagons... The Bestagons were the obvious choice!

In this series of tutorials I’ll show you how I built this background.

## Part one: how to render a hexagon?

OK, so how do we render a regular hexagon? We want to draw 6 straight lines of equal length. To form a hexagon, the angle between every two sides has to be 120°.

:::note
Each time we add a side to a polygonal shape, the sum of its interior angles increase by 180°. So a triangle has a total of 180°, a square - 360°, a pentagon - 540°, and a hexagon - 720°.

A hex has six sides, and from the formula `degrees = (# of sides - 2) * 180`, we can compute the angle size of 720 / 6 = **120°**.
:::

![hex-1.png](/images/hexagons-are-the-bestagons-js-edition-part-one/hex-1.png)

Let’s explore our options for drawing stuff on a canvas. Here's some API methods from [CanvasRenderingContext2D](https://developer.mozilla.org/en-US/docs/Web/API/CanvasRenderingContext2D), the interface from the Canvas API that we use to draw in two dimensions:

- [arc()](https://developer.mozilla.org/en-US/docs/Web/API/CanvasRenderingContext2D/arc) - creates a circular arc. Hexagons only have straight walls, `arc` is definitely not our thing;
- [ellipse()](https://developer.mozilla.org/en-US/docs/Web/API/CanvasRenderingContext2D/ellipse) - creates an ellipse. Same as above, cool, but not for us;
- [rect()](https://developer.mozilla.org/en-US/docs/Web/API/CanvasRenderingContext2D/rect) - adds a rectangle to the current path. Finally, some straight lines. Still won’t work for us though - rectangles are obviously the inferior choice... and we can't really draw a hex using a full reactangle;
- [lineTo()](https://developer.mozilla.org/en-US/docs/Web/API/CanvasRenderingContext2D/lineTo) - adds a straight line to the current sub-path. This is our thing!

Unfortunately, there doesn’t seem to be anything more convenient in the API. No `fillHex()` function yet 🙄. We’ll have to draw our hexagons line by line.

So, let’s take a look at the `lineTo()` method - it accepts an `x` and a `y` coordinate. Here’s the example from MDN:

```js
const canvas = document.getElementById("canvas");
const ctx = canvas.getContext("2d");

ctx.beginPath(); // Start a new path
ctx.moveTo(30, 50); // Move the pen to (30, 50)
ctx.lineTo(150, 100); // Draw a line to (150, 100)
ctx.stroke(); // Render the path
```

OK, so in order to draw a hex, we need to figure out the coordinates of all its vertices.

## Computing the vertices

Let’s give the vertices of our future Hex names - A, B, C, D, E, F:

![hex-2.png](/images/hexagons-are-the-bestagons-js-edition-part-one/hex-2.png)

And let’s say we start from vertex A. Our code will then look something like this:

```js
const canvas = document.getElementById("canvas");
const ctx = canvas.getContext("2d");

ctx.beginPath(); // Start a new path
ctx.moveTo(vertexA.x, vertexA.y); // move the pen to vertex A
ctx.lineTo(vertexB.x, vertexB.y); // draw a line from A to B
ctx.lineTo(vertexC.x, vertexC.y); // draw a line from B to C
ctx.lineTo(vertexD.x, vertexD.y); // draw a line from C to D
ctx.lineTo(vertexE.x, vertexE.y); // draw a line from D to E
ctx.lineTo(vertexF.x, vertexF.y); // draw a line from E to F
ctx.lineTo(vertexA.x, vertexA.y); // ...and finally, from F to A to finish the hex
ctx.closePath();
ctx.stroke(); // Render the path
```

The next question we have to answer is - if vertex A has coordinates `(0, 0)`, where is vertex B?

![brace-yourselves.jpg](/images/hexagons-are-the-bestagons-js-edition-part-one/brace-yourselves.jpg)

First, we need to define the length of our hex’s side. Let’s hardcode it to `10px`.  Then, figure out where B is.

![hex-3.png](/images/hexagons-are-the-bestagons-js-edition-part-one/hex-3.png)

Let’s call the coordinates of A `(ax, by)` , and of B `(bx, by)` . We draw a line between A and C and the height of the ABC triangle - BH.

We can now see that:

- `bx == ax + length(AH)` - B is straight on top of H, so `bx` is the same as the `x` coordinate of H (`hx`); H is `length(AH)` away from A, so `hx` is `ax + length(AH)`
- `by == ay - length(BH)` - B is `length(BH)` away from H, so `by = hy - length(BH)`; and because A and H are on the same `y` → `hy` is the same as `ay`.

If we find the lengths of AH and BH, we’re good to go. To find them, we need a bit of math “magic”:

- `∠AHB` is **90°**. `∠ABH` is half of `∠ABC`, so it’s **60°**, therefore `∠HAB` is 180 - (90 + 60) = **30°**.
- From trigonometry, [we know](https://www.khanacademy.org/math/trigonometry/trigonometry-right-triangles/sine-and-cosine-of-complementary-angles/a/trig-ratios-of-special-triangles) that `length(AH) = cos(∠HAB) * length(AB)`, and `length(BH) = sin(∠AHB) * length(AB)`

Let's call the length of AB `hexSide`, then:

- `length(AH) = cos(30°) * hexSide`
- `length(BH) = sin(30°) * hexSide`

## Math over!

We’re mostly done with the math. Back to code!

```js
const COS_30 = Math.cos(Math.PI / 6);
const SIN_30 = Math.sin(Math.PI / 6);

const hexSide: number = 10; // the side of our hex is hardcoded to 10px

// Note: in real life, lacking the diagram above, `AH` means nothing.
// I would keep this as `COS_30 * hexSide` or try to give a more
// meaningful name.
const AH = COS_30 * hexSide;
const BH = SIN_30 * hexSide;

const vertexA = { x: 0, y: 0 };
const vertexB = { x: vertexA.x + AH, y: vertexA.y - BH };
```

And we have our vertex B!

At this point I suggest you pause for a bit and try to figure out the coordinates of C, D, E, and F. Use what we already know - the coordinates of A and B, `hexSide`, `AH`, and `BH`.

Here’s the solution:

```js
const vertexA = { x: 0, y: 0 };
const vertexB = { x: vertexA.x + AH, y: vertexA.y - BH };
const vertexC = { x: vertexB.x + AH, y: vertexA.y };
const vertexD = { x: vertexC.x, y: vertexC.y + hexSide };
const vertexE = { x: vertexB.x, y: vertexD.y + BH };
const vertexF = { x: vertexA.x, y: vertexD.y };
```

So, now that we have all vertex coordinates, we're finally ready to render our hexagon:
```html
<html>
  <body>
    <canvas id="canvas"></canvas>
    <script>
    const COS_30 = Math.cos(Math.PI / 6);
    const SIN_30 = Math.sin(Math.PI / 6);

    // Coords of our first vertex.
    const start = { x: 100, y: 100 };

    // Length of our hex's side.
    const hexSide = 100;

    // Find or create a canvas.
    const canvas = document.querySelector('#canvas');
    canvas.width = 400;
    canvas.height = 400;

    const ctx = canvas.getContext('2d');

    // Compute the vertices (same as above).
    const vertexA = start;
    const vertexB = {
      x: vertexA.x + hexSide * COS_30,
      y: vertexA.y - hexSide * SIN_30
    };
    const vertexC = { x: vertexB.x + hexSide * COS_30, y: vertexA.y };
    const vertexD = { x: vertexC.x, y: vertexC.y + hexSide };
    const vertexE = { x: vertexB.x, y: vertexD.y + hexSide * SIN_30 };
    const vertexF = { x: vertexA.x, y: vertexA.y + hexSide };

    // List all vertices. Remember - we have to `lineTo()` to vertex A to
    // finish the hex.
    const vertices = [
      vertexA, vertexB, vertexC,
      vertexD, vertexE, vertexF, vertexA
    ];

    // Begin a new sub-path at vertex0.
    ctx.moveTo(vertices[0].x, vertices[0].y);
    ctx.beginPath();

    // Add line to the sub-path from each vertex to the next one.
    vertices.forEach(({ x, y }) => ctx.lineTo(x, y));

    // End the sub-path.
    ctx.closePath();

    // Set the stroke color for our hex.
    ctx.strokeStyle = 'rgb(0, 0, 0)';

    // And finally, our Bestagon:
    ctx.stroke();
    </script>
  </body>
</html>

```

And the outcome is:
![result.png](/images/hexagons-are-the-bestagons-js-edition-part-one/result.png)

This is it for Part one! Thank you for reading!

In Part two we will continue with rendering multiple hexes on a grid. Stay tuned 😉
